Magnetic Field Produced By Current, Part 1

Biot-Savart Law: Suppose we have a wire carrying a current I. Biot-Savart law tells us how to calculate the magnetic field produced by the current. Consider an infinitesimal segment ds of the wire. This segment produces a magnetic field dB at a point P. Let r be the vector from ds to P. Then dB = (mu_0 / 4*pi) I ds x r / r^3, where mu_0 = 4*pi*10^-7 T.m/A (Tesla*meter/Ampere). The SI unit of the magnetic field is Tesla. The constant mu_0 is called the permeability of free space. The magnetic field produced by the whole wire is then obtained by integration.
In the lecture, Biot-Savart law is applied to the calculation of the magnetic field produced by a current carrying straight wire, a semicircular wire, and a circular wire.

Magnetic Field Produced By Current, Part 1

Lecture Slides are screen-captured images of important points in the lecture. Students can download and print out these lecture slide images to do practice problems as well as take notes while watching the lecture.

Intro

Biot-Savart Law

B-Field of a Straight Wire

Semi Circular Wire

Circular Current in Loop

Example 1: Loop Carrying Current

Example 2: Concentric Loops
