RC Circuits

During the charging of a capacitor, the current in the RC circuit is given by
I ( t ) = (V/R)*exp( -t / T)

where V is the battery emf, R is the resistance, and T = RC is called the RC circuit time constant. On the other hand, the charge on the capacitor varies with time according to

Q ( t ) = CV [1 – exp( -t / T)]
When a capacitor discharges through a resistance R, the charge on the capacitor decreases with time according to Q ( t ) = Q_initial *exp ( -t / T)
